годот программирование Mesh Chunks 3

extends Node2D


static var map_cell_size: float = 1.0
static var chunk_size: int = 256
static var cell_size: float = 1.0
static var agent_radius: float = 10.0
static var chunk_id_to_region: Dictionary = {}


var path_start_position: Vector2


func _ready() -> void:
    NavigationServer2D.set_debug_enabled(true)

    path_start_position = %Node2D2.global_position

    var map: RID = get_world_2d().navigation_map
    NavigationServer2D.map_set_cell_size(map, map_cell_size)

    NavigationServer2D.map_set_use_edge_connections(map, false)

    var source_geometry: NavigationMeshSourceGeometryData2D = NavigationMeshSourceGeometryData2D.new()
    var parse_settings: NavigationPolygon = NavigationPolygon.new()
    parse_settings.parsed_geometry_type = NavigationPolygon.PARSED_GEOMETRY_STATIC_COLLIDERS
    NavigationServer2D.parse_source_geometry_data(parse_settings, source_geometry, %Node2D)

    var traversable_outline: PackedVector2Array = PackedVector2Array([
        Vector2(0.0, 0.0),
        Vector2(1920.0, 0.0),
        Vector2(1920.0, 1080.0),
        Vector2(0.0, 1080.0),
    ])
    source_geometry.add_traversable_outline(traversable_outline)

    create_region_chunks(%Node2D3, source_geometry, chunk_size * cell_size, agent_radius)


    static func create_region_chunks(chunks_root_node: Node, p_source_geometry: NavigationMeshSourceGeometryData2D, p_chunk_size: float, p_agent_radius: float) -> void:
    var input_geometry_bounds: Rect2 = p_source_geometry.get_bounds()

    var start_chunk: Vector2 = floor(
    input_geometry_bounds.position / p_chunk_size
        )
    var end_chunk: Vector2 = floor(
        (input_geometry_bounds.position + input_geometry_bounds.size)
/ p_chunk_size
)

    for chunk_y in range(start_chunk.y, end_chunk.y + 1):
        for chunk_x in range(start_chunk.x, end_chunk.x + 1):
            var chunk_id: Vector2i = Vector2i(chunk_x, chunk_y)

            var chunk_bounding_box: Rect2 = Rect2(
            Vector2(chunk_x, chunk_y) * p_chunk_size,
            Vector2(p_chunk_size, p_chunk_size),
)
            var baking_bounds: Rect2 = chunk_bounding_box.grow(p_chunk_size)

            var chunk_navmesh: NavigationPolygon = NavigationPolygon.new()
            chunk_navmesh.parsed_geometry_type = NavigationPolygon.PARSED_GEOMETRY_STATIC_COLLIDERS
            chunk_navmesh.baking_rect = baking_bounds
            chunk_navmesh.border_size = p_chunk_size
            chunk_navmesh.agent_radius = p_agent_radius
            NavigationServer2D.bake_from_source_geometry_data(chunk_navmesh, p_source_geometry)

            chunk_navmesh.baking_rect = Rect2()

            var navmesh_vertices: PackedVector2Array = chunk_navmesh.vertices
            for i in navmesh_vertices.size():
                var vertex: Vector2 = navmesh_vertices[i]
                navmesh_vertices[i] = vertex.snappedf(map_cell_size * 0.1)
            chunk_navmesh.vertices = navmesh_vertices

            var chunk_region: NavigationRegion2D = NavigationRegion2D.new()
            chunk_region.navigation_polygon = chunk_navmesh
            chunks_root_node.add_child(chunk_region)

            chunk_id_to_region[chunk_id] = chunk_region


func _process(_delta: float) -> void:
    var mouse_cursor_position: Vector2 = get_global_mouse_position()

    var map: RID = get_world_2d().navigation_map
    if NavigationServer2D.map_get_iteration_id(map) == 0:
        return

    var closest_point_on_navmesh: Vector2 = NavigationServer2D.map_get_closest_point(
map,
mouse_cursor_position
)

    if Input.is_mouse_button_pressed(MOUSE_BUTTON_LEFT):
        path_start_position = closest_point_on_navmesh

    %Node2D2.global_position = path_start_position

    %NavigationAgent2D.target_position = closest_point_on_navmesh
    %NavigationAgent2D2.target_position = closest_point_on_navmesh
    %NavigationAgent2D3.target_position = closest_point_on_navmesh

    %NavigationAgent2D.get_next_path_position()
    %NavigationAgent2D2.get_next_path_position()
    %NavigationAgent2D3.get_next_path_position()
